Product Summary

The MINISMDC075F-2 is a PolySwitch surface-mount device. It is the preferred circuit protection method for computer, consumer, multimedia, portable, and automotive electronics applications.

Parametrics

Physical characteristics: (1)Terminal pad material:100% matte tin with nickel underplate; (2)Soldering characteristics:ANSI/J-STD-002 Category 3 for femtoSMD, picoSMD, nanoSMD, microSMD and miniSMD series ANSI/J-STD-002 Category 1 for SMD series; (3)Solder heat withstand:per IEC-STD 68-2-20, Test Tb, Section 5, Method 1A; (4)Flammability resistance:per IEC 695-2-2 Needle Flame Test for 20 sec.; (5)Recommended storage conditions:40℃ max, 70% R.H. max; devices may not meet specified ratings if storage conditions are exceeded.

Features

Features: (1)RoHS compliant; (2)Halogen free; (3)Broadest range of resettable devices available in the industry; (4)Current ratings from 0.05 to 3A; (5)Voltage ratings from 6V computer and electronic applications to 60V telecom applications; (6)Agency recognition: UL, CSA, TüV; (7)Small footprint; (8)Fast time-to-trip; (9)Low resistance.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MINISMDC075F-2
MINISMDC075F-2
TE Connectivity / Raychem
PTC Resettable Fuses .75A 13.2V 100A Imax
Data Sheet
0-1: $0.19
1-10: $0.17
10-100: $0.15
100-500: $0.12
